280VAC Hybrid Solar Inverter 24v Hybrid Inverter For Personal Computers

Hybrid Solar Inverter CSI PLUS OFF GRID INVERTER 1500w-2500w-(12v-24v)

PRODUCT FEATURES of Hybrid Solar Inverter
Pure sine wave inverter.
Compatible to AC mainsor generator power.
Confiqurable AC/Solar input priority via LCD setting.
Cold start funcion.
Selectable input voltage range for home appliances andpersonel computers.
Built-in MPPT solar controller.
Auto restart while AC is recovering.
Overload/ Over temperaturelshort circuit protection.

DATASHEET of Hybrid Solar Inverter

CS IPLUS 1500-12

RATED POWE :1500W

INPUT

Voltage :230VAC

Frequency Range :170-280VAC(For Personal Computers)

                               90-280VAC(For Home Appliances)

                               50 Hz/60 Hz(Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)  :230VAC+5%

Surge Power :3000VA

Efficiency (Peak) PV to INV :97%

Efficiency (Peak) Battery to INV :94%

Transfer Time :10 ms (For Personal Computers); 20 ms (For Home Appliances)

Waveform :Pure sine wave

BATTERY & AC CHARGER

Battery Voltage :12 VDC
Floating Charge Voltage :13.5VDC

Overcharge Protection :16 VDC
Maximum Charge Current :80A

SOLAR CHARGER

Maximum PV Array Power :2000W
MPPT Range @ Operating Voltage :60~430VDC

Maximum PV Array Open Circuit Voltage :450VDC
Maximum Charging Current :80A
Maximum Efficiency :98%


PHYSICAL

Dimension,D x Wx H(mm) :128*300*363

Net Weight (kgs) :6.9
Communication interface :USB/RS232

OPERATING ENVIRONMENT

Humidity :5% to 95% Relative Humidity(Non-condensing)
Operating Temperature :0°C-55°C
Storage Temperature :-15°C-60°C

Our Services

1. keep the quality first and make more products benefit to our customers' need

2. about our Online/Sale service

1) super and solid quality

2) Fast and punctual delivery

3) Standard export package or as customers’ need.

3. After-sale service

1) Assistance to your project

2) Repairing and maintenance if any problem occur in the warranty.

3) Installation and clerks training

4) Spare and wearing parts for free or with big discount

5) Any feedback of machines can be told to us, and we will try our best to support you.

4. Other cooperation service

1) Technology knowledge share

2) Factory building advising

3) Business expansion advising

Packaging:

1. Plywood or wooden case
2. Adhesive wrap to prevent scratches
3. Plastic film to keep the machine together
4. Foam plate and block to prevent shake
5. Other customer's requirements

FAQ:

1. Are you a trading company or manufacturer?

We are manufacturer in Shenzhen, China, specialized in frequency inverter,Hybrid Solar Inverter and portable water cooling

induction heater/induction heating machine for many years.

2. What's the delivery time for sample and bulk order?

Normally for machines in stock, will deliver within 5 days, if not, 7-30 days according to your order.

3. What's your quality guarantee period?

12 months warranty

4. Can I get a lower price if I order large quantities?

Of course. Cheaper price with larger quantity

5. can you customize the machine for us?

Yes, of course, just tell me your detailed requirement, so I can suggest you most suitable model.
