RS485 Frequency Drive Inverter Superoverload Capacity PMSM Motor Driver
Place of Origin Shenzhen, China
Brand Name Canroon
Certification CE ISO9001
Model Number CV900A
Minimum Order Quantity 1
Price negotiated price
Packaging Details carton box
Delivery Time 5-7 days
Payment Terms L/C, T/T, Western Union,Paypal
Supply Ability 3000 Piece/Pieces per Week
Product Details
Control Mode Permanent Magnet Synchronous Motor Current Flux/sensorless Vector Control, V/f Control Communication Setting RS485, CAN (customizable Upon Request)
Ambient Humidity 5-90%RH Non-condensing Carrier Frequency 2-15kHz
Operating Status Signal Relay Output Signal: Fault Output, Conditional Function Output Overload Capacity 150% Rated Current For 60 Seconds
Ambient Temperature -10℃~+40℃ Protection Level IP20
Highlight

RS485 Frequency Drive Inverter

,

Superoverload Capacity Frequency Drive Inverter

,

Superoverload Capacity PMSM Motor Driver

Product Description

Frequency Drive Inverter RS485 Control Input Signal Oil Start Stop Instructions PMSM Driver

Product Description:

The CV900A series PMSM driver is a high-performance universal current vector PMSM driverdesigned specifically for driving permanent magnet synchronous motors. The producthas low-speed high-torque output, excellent dynamic characteristics, and superoverload capacity. it is mainly used to control and regulate the speed and torque ofthree-phase AC synchronous motors, and can easily achieve high-performance vectorcontrol of permanent magnet synchronous motors. lt is applied in servo drives forhydraulic control direction.



Frequency Drive Inverter is a type of high-performance vector control device, designed for three-phase AC 323V ~ 528V, -10℃~+40℃ ambient temperature. The input frequency is 50/60Hz+5%, and the maximum speed can be converted to 2000Hz according to the output frequency. It is of super overload capacity. Moreover, it supports KTY, PTC temperature protection and overload protection, making it a reliable and secure choice.



Features:

  • Product Name: CV900A PMSM driver
  • Rated Voltage and Frequency: Three-phase AC 323V ~ 528V
  • Carrier Frequency: 2-15kHz
  • Motor Protection: Overload Protection, Supports KTY, PTC Temperature Protection
  • Ambient Humidity: 5-90%RH Non-condensing
  • Communication setting: RS485, CAN (customizable Upon Request)
  • Low-speed high-torque output, designed specifically for driving permanent magnet synchronous motors
  • High-performance vector control

Technical Parameters:

Parameter Details
Input Frequency 50/60Hz+5%
Operating Status Signal Relay Output Signal: Fault Output, Conditional Function Output
Wiring Method Terminal Block
Ambient Temperature -10℃~+40℃
Ambient Humidity 5-90%RH Non-condensing
Rated Voltage and Frequency Three-phase AC 323V ~ 528V
Motor Protection Overload Protection, Supports KTY, PTC Temperature Protection
Maximum Speed Converted To 2000Hz According To The Output Frequency
Operational Control Input Signal: Oil Start And Stop Instructions
Overload Capacity 150% Rated Current For 60 Seconds
Easy And Simple Debugging CV900A PMSM Drive
High-performance vector control Yes

Applications:

Canroon CV900A Frequency Drive Inverter is a high-performance universal current vector PMSM driver. It offers superior overload capacity, low-speed high-torque output and intelligent fast-response control. The input frequency of the product is 50/60Hz+5%, while its rated voltage and frequency is three-phase AC 323V ~ 528V. Additionally, the product can be converted to 2000Hz according to the output frequency, and it is also able to provide RS485/CAN communication, high-precision current control, overload protection, and KTY temperature protection. The product is CE and ISO9001 certified.



RS485 Frequency Drive Inverter Superoverload Capacity PMSM Motor Driver 0

Support and Services:

Frequency Drive Inverter Technical Support and Service

We are dedicated to providing our customers with the best technical support and service for our Frequency Drive Inverter. Our team of experienced technicians is available to answer any questions you may have. To ensure that you get the most out of your product, we provide detailed instructions for installation and troubleshooting. We also offer free online tutorials and video support to help you get the most out of your Frequency Drive Inverter.

We understand that sometimes problems can arise with your Frequency Drive Inverter. In the event that you experience an issue, our knowledgeable customer service representatives are standing by to help. We offer a comprehensive warranty for our Frequency Drive Inverter, and we are always available to answer any questions or provide you with advice.

At Frequency Drive Inverter, we are committed to making sure that our customers are satisfied with our products and services. We strive to provide the highest quality of technical support and customer service. If you have any questions or concerns, please do not hesitate to contact us.



RS485 Frequency Drive Inverter Superoverload Capacity PMSM Motor Driver 1

RS485 Frequency Drive Inverter Superoverload Capacity PMSM Motor Driver 2

Packing and Shipping:

Frequency Drive Inverter Packaging and Shipping

Frequency Drive Inverter should be packaged to protect against damage during shipping. The following procedures should be followed:

  • Place the Frequency Drive Inverter into a box and fill any empty space with cushioning material.
  • Secure the box closed with packing tape, making sure to cover all openings.
  • Label the box with the shipping address and a clear indication of the contents.
  • Ensure that the box is strong enough to protect the Frequency Drive Inverter during shipping.
  • Use a shipping service that specializes in shipping delicate electronics.

FAQ:

Q1: What is the brand name of the Frequency Drive Inverter?
A1: The brand name of the Frequency Drive Inverter is Canroon.

Q2: What is the model number of the Frequency Drive Inverter?
A2: The model number of the Frequency Drive Inverter is CV900A.

Q3: Where is the Frequency Drive Inverter manufactured?
A3: The Frequency Drive Inverter is manufactured in Shenzhen, China.

Q4: Does the Frequency Drive Inverter have certifications?
A4: Yes, the Frequency Drive Inverter has CE and ISO9001 certifications.

Q5: What is the minimum order quantity for the Frequency Drive Inverter?
A5: The minimum order quantity for the Frequency Drive Inverter is 1.
