Torque Control Ac Motor Inverter Drive Mini Compact Structure
Product Details
| Control Mode | V/F Control, Simple Vector Control, Advanced Vector Control, Torque Control | Voltage Range | 380V-480V |
|---|---|---|---|
| Humidity | 5%~95%RH，without Condensing Drops | Operation Temperature | -10℃~+40℃ |
| Overload Capacity | 10% For Long-term, 150% For 1 Min, 180% For 5s | Cooling Method | Air Cooling With Fan Control |
| Output Voltage | 4T: 0~380V 2S:0~220V | Counter | A Built-in Counter, Facilitate System Integration |
| Highlight | Torque Control Ac Motor Inverter Drive,Mini Ac Motor Inverter Drive,Compact Structure Ac Motor Inverter |
||
Product Description
VFD Widely Used Air Cooling With Fan Control Small Automatic Machinery Facilitate System Mini Inverter
Product Description:
VFD Frequency Inverter is a reliable and cost-efficient device, which can be widely used in small automatic machinery represented byglass edging, food fling, mini inverter, etc. It has strong overload capacity, with 10% for long-term, 150% for 1 minute, and 180% for 5s. The input frequency range from 50/60 Hz, and the operation temperature is from -10℃ to +40℃. What's more, it has a perfect temperature control with effective air cooling with fan control, and it can also work in humidity range of 5% - 95% RH without condensing drops. VFD Frequency Inverter is not only good at performance, but also easily operated.
Features:
- Product Name: VFD Frequency Inverter
- Voltage Range: 380V-480V
- Operation Temperature: -10℃~+40℃
- Counter: A Built-in Counter, Facilitate System Integration
- Low Noise Running: Carrier Frequency 2.0kHz-20.0kHz Continuous Adjustable, Minimize Motor Noise
- Humidity: 5%~95%RH, without Condensing Drops
- Mini Inverter: Compact Structure, Facilitate System Integration
- Multi-Function Inverter: Low Noise Running, High Efficiency
Technical Parameters:
| Name | Parameter |
| Counter | A Built-in Counter, Facilitate System Integration |
| Display | LED |
| Voltage Range | 380V-480V |
| Input Frequency | 50/60Hz |
| Overload Capacity | 10% For Long-term, 150% For 1 Min, 180% For 5s |
| Output Voltage | 4T: 0~380V 2S:0~220V |
| Protection Level | IP20 |
| Operation Temperature | -10℃~+40℃ |
| Output Frequency | 0.00-999.9Hz |
| Acceleration and Deceleration Time Setting | 0.1s-999.9min Continuous Setting |
| Operation | Stable And Reliable Operation |
| Size |
Small Power And Small Volume, Compact Design Beyond Imagination. |
Applications:
Canroon's CV800E VFD Frequency Inverter is widely used in small automatic machinery, making it a perfect mini inverter for motor speed control. It has a brand name of Canroon, Model Number of CV800E, Place of Origin of Shenzhen, China and is certified by CE and ISO9001. It has a minimum order quantity of 1, a price that can be negotiated, and it comes packaged in a carton box. Delivery time is 3-7 days with payment terms of L/C, T/T, Western Union, Paypal. The supply ability is 3000 Piece/Pieces per week. The display is LED, humidity is 5%~95%RH,without condensing drops, and the output frequency is 0.00-999.9Hz. It runs at low noise with a carrier frequency of 2.0kHz-20.0kHz that can be continuously adjusted to minimize motor noise. The input frequency is 50/60Hz. This VFD Frequency Inverter is a perfect mini inverter for motor speed control, and it is highly reliable, efficient, and cost-effective.
Support and Services:
VFD Frequency Inverter Technical Support and Service
We provide technical support and services for VFD frequency inverter products. Our experienced technical staff are available for troubleshooting, maintenance, and repair. Our services include:
- Troubleshooting
- System maintenance
- Software and firmware updates
- Repair and replacement of components
- Customization
- Technical advice
We can also provide training and support for installation, commissioning, and operation of VFD frequency inverter products. Our team is committed to providing the highest quality of service and support.
FAQ:
Q: What is the Brand Name of the VFD Frequency Inverter?
A: The Brand Name of the VFD Frequency Inverter is Canroon.
Q: What is the Model Number of the VFD Frequency Inverter?
A: The Model Number of the VFD Frequency Inverter is CV800E.
Q: Where is the Place of Origin of the VFD Frequency Inverter?
A: The Place of Origin of the VFD Frequency Inverter is Shenzhen, China.
Q: What is the Certification of the VFD Frequency Inverter?
A: The Certification of the VFD Frequency Inverter is CE ISO9001.
Q: What is the Minimum Order Quantity of the VFD Frequency Inverter?
A: The Minimum Order Quantity of the VFD Frequency Inverter is 1.
